1 | import numpy as np |
---|

2 | from numpy import exp, sin, cos, pi, radians, degrees |
---|

3 | |
---|

4 | from sasmodels.weights import Dispersion as BaseDispersion |
---|

5 | |
---|

6 | class Dispersion(BaseDispersion): |
---|

7 | r""" |
---|

8 | Cyclic gaussian dispersion on orientation. |
---|

9 | |
---|

10 | .. math: |
---|

11 | |
---|

12 | w(\theta) = e^{-\frac{\sin^2 \theta}{2 \sigma^2}} |
---|

13 | |
---|

14 | This provides a close match to the gaussian distribution for |
---|

15 | low angles (with $\sin \theta \approx \theta$), but the tails |
---|

16 | are limited to $\pm 90^\circ$. For $\sigma$ large the |
---|

17 | distribution is approximately uniform. The usual polar coordinate |
---|

18 | projection applies, with $\theta$ weights scaled by $\cos \theta$ |
---|

19 | and $\phi$ weights unscaled. |
---|

20 | |
---|

21 | This is closely related to a Maier-Saupe distribution with order |
---|

22 | parameter $P_2$ and appropriate scaling constants, and changes |
---|

23 | between $\sin$ and $\cos$ as appropriate for the coordinate system |
---|

24 | representation. |
---|

25 | """ |
---|

26 | type = "cyclic_gaussian" |
---|

27 | default = dict(npts=35, width=1, nsigmas=3) |
---|

28 | |
---|

29 | # Note: center is always zero for orientation distributions |
---|

30 | def _weights(self, center, sigma, lb, ub): |
---|

31 | # Convert sigma in degrees to the approximately equivalent Maier-Saupe "a" |
---|

32 | sigma = radians(sigma) |
---|

33 | a = -0.5/sigma**2 |
---|

34 | |
---|

35 | # Limit width to +/-90 degrees; use an open interval since the |
---|

36 | # pattern at +90 is the same as that at -90. |
---|

37 | width = min(self.nsigmas*sigma, pi/2) |
---|

38 | x = np.linspace(-width, width, self.npts+2)[1:-1] |
---|

39 | wx = P(x, a) |
---|

40 | |
---|

41 | # Return orientation in degrees with Maier-Saupe weights |
---|

42 | return degrees(x), exp(a*sin(x)**2) |
---|

43 | |
---|
